Cov khoom
10ft Ib chav pw Ib chav da dej Prefab tsev
Yog tias koj xav tau qhov chaw nyob ntau dua li lub thawv ntim khoom tab sis tseem xav tau tus nqi thauj khoom qis, qhov 10ft expandable tis quav tsev hits qhov chaw qab zib zoo kawg nkaus. Nws ships folded nruj zoo li lub thawv tsis tu ncua, ces ob sab tis swb tawm ntawm qhov chaw mus ze li peb npaug ntawm thaj chaw siv tau. Ob tus neeg ua haujlwm tuaj yeem ua tiav qhov teeb tsa tag nrho nyob ib ncig ntawm ob teev nrog cov cuab yeej yooj yim.
Ntau tus neeg yuav khoom xaiv cov qauv no vim tias nws daws qhov mob taub hau loj tshaj plaws ntawm prefab vaj tsev: them tag nrho cov thawv thauj khoom rau ib chav tsev me me. Thaum folded, nws yuav siv sij hawm ntau qhov chaw tshaj li tus qauv 10ft thawv, yog li plaub chav ua tiav haum rau hauv ib lub thawv 40HQ rau kev txiav txim ntau. Thaum nthuav tawm, koj tau txais tag nrho 18.5㎡ hneev taw nrog thaj chaw nyob, chav pw thiab chav dej - txaus chav rau ob mus rau plaub tus neeg yooj yim. Nws ua haujlwm tau zoo raws li lub vaj tsev sab nraum zoov, chaw ua haujlwm me me, lub tsev so ib ntus lossis ntawm -cov neeg ua haujlwm chaw nyob.
Muaj nuj nqi
Nqe lus piav qhia
Folded thauj loj ntsuas 2950mm ntev, 2200mm dav thiab 2480mm siab. Tom qab ob sab tis tau tag nrho txuas ntxiv thiab kaw, cov qhov ntev sab nraud nthuav dav mus rau 2950mm × 6300mm × 2480mm, nrog rau qhov chaw sab hauv siv tau li ntawm 16.5㎡.
Qhov nruab nrab ntawm cov tub ntxhais tseem nyob ruaj khov, thiab ob sab tis quav tawm ntawm hnyav -lub luag haujlwm 130mm galvanized hinges. Tag nrho cov phab ntsa vaj huam sib luag, ru tsev ntu thiab hauv pem teb qhov chaw nyob txuas nrog tag nrho cov txheej txheem folding, yog li tsis muaj pawg xoob los txheeb xyuas thaum koj teeb tsa. Hauv pem teb siv 18 hli tuab hluav taws kub- tiv taus magnesium oxide boards, ruaj khov txaus rau cov rooj tog zaum niaj hnub thiab ko taw. Sab nrauv phab ntsa yog tsim nrog 75 hli EPS sandwich panels, thiab sab hauv muab faib phab ntsa siv 50 hli panels rau thermal rwb thaiv tsev thiab suab dampening.
Ib qhov hluav taws kub steel- ntsuas qhov rooj nkag rau pem hauv ntej, thiab plaub 930 × 930mm PVC casement qhov rais cia nyob rau hauv ntau lub teeb ntuj thoob plaws ob sab phab ntsa. Lub tshuab hluav taws xob tag nrho 220V khiav ua ntej-wired los ntawm lub Hoobkas, suav nrog cov teeb ci qab nthab, lub qhov hluav taws xob thiab lub teeb hloov pauv, npaj txhij txuas ncaj qha rau lub zog hluav taws xob.
Key Tsim Paub meej
Galvanized Steel Main Ncej
Cov tub ntxhais thav duab siv tuab galvanized square tubes - 80 × 80 × 2.5mm rau sab saum toj kab kab, 80 × 100 × 2.75mm rau hauv qab sab beams - welded khoom rau ntev - lub sij hawm structural zog. Wing thav duab siv sib dua 40 × 80 × 1.5mm P- zoo li tus thiab square tubes. Txhua qhov steel mus los ntawm electrostatic hmoov txheej nyob rau hauv dawb dawb tag los tiv thaiv xeb thiab sab nraum zoov huab cua. Plaub galvanized lifting lugs zaum saum cov ces kaum kom yooj yim crane tuav.
EPS Sandwich phab ntsa & ru tsev panels
Sab nrauv phab ntsa, pem hauv ntej thiab nram qab vaj huam sib luag siv 950-hom 65mm tuab EPS xim steel sandwich panels nrog 0.3mm steel tawv ntawm ob sab. ru tsev panels ntxiv ib qho ntxiv 0.4mm corrugated steel ntawv rau sab nraud kom zoo dua los nag los nag thiab huab cua tiv thaiv. Sab hauv qab nthab thiab phab ntsa muab faib siv 50mm tuab EPS sandwich panels. EPS core muab cov txheej txheem thermal rwb thaiv tsev kom sov sab hauv tsev kom ruaj khov dua li lub tiaj tiaj steel.
Ua ntej -Wired Electrical Setup
Tag nrho chav tsev khiav ntawm 220V 50Hz txheem mov. Kev ntsuas hluav taws xob sib tw txhua lub voj voog: 6mm² rau cov kab nkag tseem ceeb, 4mm² rau cov cua txias qhov hluav taws xob, 2.5mm² rau cov qhov hluav taws xob tsis tu ncua thiab 1.5mm² rau cov teeb pom kev zoo. Cov teeb ci ntsa iab loj muab lub teeb pom kev zoo, thiab tus qauv 3-pin / 5-pin thoob ntiaj teb sockets nruab rau ntawm phab ntsa yooj yim. Qhov (socket) thiab hloov cov qauv tuaj yeem hloov kho kom haum rau ntau lub teb chaws.
Common Usage Scenarios
1.Backyard qhua suite lossis cov laus niam txiv tsev
2.Me me ntawm - chaw ua haujlwm tsim kho nrog thaj chaw so
3.Holiday park xauj tsev rau 2-4 qhua
4. Tej thaj chaw deb cov neeg ua haujlwm chaw nyob
5. Ib ntus pop- nce qhov chaw muag khoom lossis chaw txais tos
6.Small home studio lossis hobby rhiav
Kev hloov kho tshiab
- Cov chav dej tag nrho nrog da dej, chav dej thiab dab dej
- Ua- hauv chav ua noj yooj yim txee nrog dab dej
- Phab ntsa-mounted cua txias chav tsev
- Kev cai sab nrauv ntoo lis los yog kho kom zoo nkauj siding
- Ntxiv sab hauv muab faib phab ntsa
Kev xa khoom & Ntawm -Site Setup
Folding tsim yog qhov twg cov qauv no yeej txuag koj nyiaj ntawm kev xa khoom. Plaub lub folded tag nrho ntim rau hauv ib lub thawv 40ft siab lub thawv, txiav ib -unit dej hiav txwv freight ho piv nrog rigid non-foldable tsev.
Ntawm qhov chaw, koj tsuas yog xav tau lub tiaj tus, theem hauv paus - pob zeb compacted, pob zeb ua pob zeb lossis pier footings tag nrho ua haujlwm zoo. Ob tus neeg ua haujlwm nthuav tawm ob sab tis, xauv tag nrho cov bolts txuas, kaw cov pob qij txha hauv pem teb nrog cov txheej txheem sealant, tom qab ntawd txuas rau lub ntsiab fais fab cable. Kev teeb tsa yooj yim yuav siv sij hawm kwv yees li ob teev los ntawm kev xa khoom kom npaj tau -rau- siv. Peb muab cov khoom siv me me nrog cov ntaub nplaum tsis muaj dej, nqa cov hlua, cov khoom siv nplaum thiab rab phom caulking los npog tag nrho ntawm - qhov chaw ua haujlwm.
Technical Specifications
|
Qeb |
Yam khoom |
Specification |
Chav tsev |
Qty |
|
Basic Dimensions |
Expanded sab nrauv |
L2950 × W6300 × H2480mm |
Teeb |
1 |
|
Internal usable loj |
L2690 × W6140 × H2240mm |
Teeb |
1 |
|
|
Folded thauj loj |
L2950 × W2200 × H2480mm |
Teeb |
1 |
|
|
Ko taw thaj tsam |
18.5 ㎡ |
/ |
/ |
|
|
Net nyhav |
2.3t ua |
/ |
/ |
|
|
Nyob |
2-4 tus neeg |
/ |
/ |
|
|
Main Ncej |
Sab saum toj beam |
80 × 80 × 2.5mm galvanized square raj |
/ |
/ |
|
Qab sab beam |
80 × 100 × 2.75mm galvanized square raj |
/ |
/ |
|
|
Sab saum toj ncej |
40 × 80 × 1.5mm P- zoo li lub raj |
/ |
/ |
|
|
Folding pob khawm |
130mm galvanized pob khawm |
Daim |
/ |
|
|
Ncej tiav |
Electrostatic hmoov txheej, dawb |
/ |
/ |
|
|
Phab ntsa & ru tsev |
Sab nrauv phab ntsa |
950-type 65mm EPS sandwich vaj huam sib luag, 0.3mm steel daim tawv nqaij |
/ |
/ |
|
Sab hauv vaj huam sib luag |
950-type 50mm EPS sandwich vaj huam sib luag |
/ |
/ |
|
|
Sab nrauv vaj huam sib luag |
50mm EPS vaj huam sib luag + 0.4mm corrugated steel ntawv |
/ |
/ |
|
|
Qab nthab vaj huam sib luag |
950-type 50mm EPS sandwich vaj huam sib luag |
/ |
/ |
|
|
Pem teb |
Main pem teb board |
18mm hluav taws kub-resistant magnesium oxide board |
Teeb |
1 |
|
Qhov rooj |
Qhov rooj nkag |
Hlau hluav taws- ntsuas qhov rooj, 840 × 2035mm |
Teeb |
1 |
|
Qhov rai |
Casement qhov rais |
PVC sab hauv qhib, 930 × 930mm |
Teeb |
4 |
|
Hluav taws xob System |
Qhov hluav taws xob |
220V, 50Hz |
/ |
/ |
|
Main xaim xaim |
6mm 2 kwg |
/ |
/ |
|
|
Qab nthab teeb |
Loj qab nthab teeb |
Teeb |
/ |
|
|
Lub qhov hluav taws xob |
International 3-pin / 5-pin sockets |
Daim |
/ |
|
|
Kev xa khoom |
40HQ thawv load |
4 units rau 40ft siab thawv thawv |
/ |
/ |
Vim li cas thiaj xaiv peb?
Tag nrho cov khoom siv steel hlau thiab cov khoom siv tsis muaj dej tsis zoo ntawm peb cov thawv ntim khoom ntim tau raws li European cov khoom lag luam sab nraum zoov. Peb tau kho qhov teeb meem zoo ib yam ntawm cov thawv ntim khoom zoo tib yam ntawm kev ua lag luam xws li xeb yooj yim, cua tsis zoo condensation thiab xoob folding buckles.
- 90% ntawm cov neeg muag khoom tuaj xyuas muab xaj tam sim tom qab kuaj xyuas lub Hoobkas
- 85% ntawm cov neeg siv khoom txawv teb chaws tso rov qab xaj dua
- Muaj 46,000 ㎡ loj - nplai kev koom ua ke ntau lawm Hoobkas
- 3,000 teeb tsa siab tshaj plaws txhua xyoo muaj peev xwm rau folding thawv series
